Interconnect: OSHP District 10 Post Dispatch - ODOT Statewide TMC
(Click on image to view full-size)
(E) = Existing Flow
(P) = Planned/Future Flow
(E/P) = Existing and Planned Flow - Flow appears as Existing and Planned
Source
Architecture Flows
Destination
OSHP District 10 Post Dispatch
alert notification (P)
resource request (P)
resource deployment status (P)
remote surveillance control (P)
incident response status (P)
incident information (P)
ODOT Statewide TMC
ODOT Statewide TMC
alert status (P)
road network conditions (P)
resource request (P)
resource deployment status (P)
incident response status (P)
incident information (P)
traffic images (E)
OSHP District 10 Post Dispatch
