Interconnect: OSHP Districts 1 and 2 Posts Dispatch - ODOT Statewide TMC
(Click on image to view full-size)
(E) = Existing Flow
(P) = Planned/Future Flow
(E/P) = Existing and Planned Flow - Flow appears as Existing and Planned
Source
Architecture Flows
Destination
OSHP Districts 1 and 2 Posts Dispatch
alert notification (P)
resource request (P)
resource deployment status (P)
remote surveillance control (P)
incident response status (P)
incident information (P)
ODOT Statewide TMC
ODOT Statewide TMC
alert status (P)
resource request (P)
resource deployment status (P)
incident response status (P)
incident information (P)
traffic images (E)
road network conditions (P)
OSHP Districts 1 and 2 Posts Dispatch
