Toledo Regional ITS Architecture Update (Final)

Interconnect: City of Bowling Green Public Safety Dispatch - City of Bowling Green Traffic Signal System

(Click on image to view full-size)
City of Bowling Green Public Safety Dispatch - City of Bowling Green Traffic Signal System

(E) = Existing Flow
(P) = Planned/Future Flow
(E/P) = Existing and Planned Flow - Flow appears as Existing and Planned
SourceArchitecture FlowsDestination
City of Bowling Green Public Safety Dispatch resource request (P)
incident response status (P)
incident information (P)
City of Bowling Green Traffic Signal System
City of Bowling Green Traffic Signal System resource deployment status (P)
incident information (P)
road network conditions (P)
City of Bowling Green Public Safety Dispatch
