Toledo Regional ITS Architecture Update (Final)

Interconnect: City of Toledo Traffic Management System - OSHP Districts 1 and 2 Posts Dispatch

(Click on image to view full-size)
City of Toledo Traffic Management System - OSHP Districts 1 and 2 Posts Dispatch

(E) = Existing Flow
(P) = Planned/Future Flow
(E/P) = Existing and Planned Flow - Flow appears as Existing and Planned
SourceArchitecture FlowsDestination
City of Toledo Traffic Management System road network conditions (P)
resource deployment status (P)
incident information (P)
OSHP Districts 1 and 2 Posts Dispatch
OSHP Districts 1 and 2 Posts Dispatch resource request (P)
remote surveillance control (P)
incident response status (P)
incident information (P)
City of Toledo Traffic Management System
