Toledo Regional ITS Architecture Update (Final)

Interconnect: City of Toledo Public Safety Dispatch - ODOT District 2 Office

(Click on image to view full-size)
City of Toledo Public Safety Dispatch - ODOT District 2 Office

(E) = Existing Flow
(P) = Planned/Future Flow
(E/P) = Existing and Planned Flow - Flow appears as Existing and Planned
SourceArchitecture FlowsDestination
City of Toledo Public Safety Dispatch resource request (P)
remote surveillance control (P)
incident information (P)
ODOT District 2 Office
ODOT District 2 Office traffic images (P)
road network conditions (P)
resource deployment status (P)
incident response status (P)
incident information (P)
City of Toledo Public Safety Dispatch
