Toledo Regional ITS Architecture Update (Final)

Interconnect: OSHP District 1 and 2 Vehicles - OSHP Districts 1 and 2 Posts Dispatch

(Click on image to view full-size)
OSHP District 1 and 2 Vehicles - OSHP Districts 1 and 2 Posts Dispatch

(E) = Existing Flow
(P) = Planned/Future Flow
(E/P) = Existing and Planned Flow - Flow appears as Existing and Planned
SourceArchitecture FlowsDestination
OSHP District 1 and 2 Vehicles incident status (P)
emergency vehicle tracking data (P)
emergency dispatch response (P)
OSHP Districts 1 and 2 Posts Dispatch
OSHP Districts 1 and 2 Posts Dispatch suggested route (P)
emergency dispatch requests (P)
OSHP District 1 and 2 Vehicles
