Interconnect: ODOT District 2 Office - Wood County Communications
(Click on image to view full-size)
(E) = Existing Flow
(P) = Planned/Future Flow
(E/P) = Existing and Planned Flow - Flow appears as Existing and Planned
Source
Architecture Flows
Destination
ODOT District 2 Office
road weather information (P)
emergency traffic control information (P)
traffic images (P)
resource deployment status (P)
incident response status (P)
incident information (P)
road network conditions (P)
Wood County Communications
Wood County Communications
emergency traffic control request (P)
resource request (P)
remote surveillance control (P)
incident information (P)
ODOT District 2 Office
