Interconnect: ODOT District 2 Office - OSHP District 10 Post Dispatch
(Click on image to view full-size)
(E) = Existing Flow
(P) = Planned/Future Flow
(E/P) = Existing and Planned Flow - Flow appears as Existing and Planned
Source
Architecture Flows
Destination
ODOT District 2 Office
road weather information (P)
road network conditions (P)
resource request (P)
resource deployment status (P)
incident response status (P)
incident information (P)
traffic images (E)
OSHP District 10 Post Dispatch
OSHP District 10 Post Dispatch
resource request (P)
resource deployment status (P)
remote surveillance control (P)
incident response status (P)
incident information (P)
ODOT District 2 Office
