Interconnect: ODOT District 2 Maintenance Garages - OSHP Districts 1 and 2 Posts Dispatch
(Click on image to view full-size)
(E) = Existing Flow
(P) = Planned/Future Flow
(E/P) = Existing and Planned Flow - Flow appears as Existing and Planned
Source
Architecture Flows
Destination
ODOT District 2 Maintenance Garages
work zone information (P)
roadway maintenance status (P)
maint and constr resource response (P)
incident information (P)
OSHP Districts 1 and 2 Posts Dispatch
OSHP Districts 1 and 2 Posts Dispatch
maint and constr resource request (P)
incident response status (P)
incident information (P)
ODOT District 2 Maintenance Garages
